Bridge cutting machine ZLBS-400

• Place of Origin:

   China

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1458240

• Place of Origin:

  China
• This machine adopts advanced automatic technologies of microcomputer controlling and automatic beam displacment. THe main components are imported, such as frequency converter, magnetoruler, laser marking lining instrument. So it is a combined multifuctional stone machine processing equipment with high precision, steady performance,good applicability and high reliblility. It is special for the cutting and processing of valuable, big board and bigabormal line, which is the only idealest synthetical stone cutting equipment in the home and present.
  Max Diameter of Sawbit 350-500mm
  Dia of Working Platform 3200x3200mm
  Max Cutting Size 3200x3200mm
  Cutting Thickness 0-80mm
  Max Lifting Travel of Cutter 200mm
  Power of Main Motor 11kw
  Oil Pump Motor 2.2kw
  General Power 15.5kw
  G.W. 6200kgs
  Machine Dimension 5800x4700x2800mm
